Okta Entity Analytics


Version	2.4.0 (View all)
Compatible Kibana version(s)	8.15.0 or higher 9.0.0 or higher
Supported Serverless project types What's this?	Security Observability
Subscription level What's this?	Basic
Level of support What's this?	Elastic

This Okta Entity Analytics integration allows users to securely stream User and Device Entity data to Elastic Security via the REST API. When integrated with Elastic Security, this valuable data can be leveraged within Elastic for risk-scoring scenarios (e.g., context enrichments) and detecting advanced analytics (UBA) use cases.

Compatibility

This module has been tested against the Core Okta API version v1.

Upgrading to v2 from v1 of the integration

In v2 of the integration the user and device data was split into separate data streams. The data ingested into your index will be the same but you may need to update device searches if you were using them.

Note

When you upgrade from v1 you will need to reconfigure the integration and enable it due to internal changes in the package. See Resolve conflicts in the Fleet documentation for details.

Data streams

The Okta Entity Analytics integration collects two types of data: user and device.

User is used to retrieve all user logs available in an organization. See more details in the API documentation here. Device is used to retrieve all device logs available in an organization. See more details in the API documentation here.

Requirements

Elastic Agent must be installed. For more details, check the Elastic Agent installation instructions.

The minimum kibana.version required is 8.9.0.

Setup

Collect data from Okta

Get the required URL namespace, which should be preceded by an organization's subdomain (tenant) or configured custom domain.
Create an Okta API Token for Authentication. Follow this guide.

Enable the integration in Elastic

In Kibana navigate to Management > Integrations.
In the search bar, type Okta Entity Analytics.
Select the Okta Entity Analytics integration and add it.
While adding the integration, add the URL and API Token that you got earlier.
Save the integration.

Usage

The Okta provider periodically contacts the Okta API, retrieving updates for users and devices, updates its internal cache of user/device metadata, and ships the updated metadata to Elasticsearch.

Fetching and shipping updates occurs in one of two processes: full synchronizations and incremental updates. Full synchronizations will send the entire list of users and devices in state, along with write markers to indicate the start and end of the synchronization event. Incremental updates will only send data for changed users/devices during that event. Changes can come in many forms, whether it be a change to the user’s or device’s metadata, or a user or device was added or deleted. By default, full synchronizations occur every 24 hours and incremental updates occur every 15 minutes. These intervals may be customized to suit your use case.

Users should ensure that full synchronization and incremental updates are not performed so frequently that they are impossible to complete within the Okta rate limits for the endpoints that are being used — for user entity analytics: /api/v1/users; and for device entity analytics: /api/v1/devices — and the volume of data that is expected from the API endpoints. Currently, Okta limits requests to /api/v1/users and /api/v1/devices to fetch at most 200 entities per request. Rate limit usage can be monitored via the Okta rate limit dashboard, and general information about Okta management rate limits is available from the Okta documentation here.

Sample Events

A user document:

		{
  "@timestamp": "2023-07-04T09:57:19.786056-05:00",
  "event": {
    "action": "user-discovered"
  },
  "okta": {
    "id": "userid",
    "status": "RECOVERY",
    "created": "2023-06-02T09:33:00.189752+09:30",
    "activated": "0001-01-01T00:00:00Z",
    "statusChanged": "2023-06-02T09:33:00.189752+09:30",
    "lastLogin": "2023-06-02T09:33:00.189752+09:30",
    "lastUpdated": "2023-06-02T09:33:00.189753+09:30",
    "passwordChanged": "2023-06-02T09:33:00.189753+09:30",
    "type": {
      "id": "typeid"
    },
    "profile": {
      "login": "name.surname@example.com",
      "email": "name.surname@example.com",
      "firstName": "name",
      "lastName": "surname"
    },
    "credentials": {
      "password": {},
      "provider": {
        "type": "OKTA",
        "name": "OKTA"
      }
    },
    "_links": {
      "self": {
        "href": "https://localhost/api/v1/users/userid"
      }
    }
  },
  "user": {
    "id": "userid"
  },
  "labels": {
    "identity_source": "okta-1"
  }
}



A device document:

		{
    "@timestamp": "2023-07-04T09:57:19.786056-05:00",
    "event": {
        "action": "device-discovered",
    },
    "okta": {
        "created": "2019-10-02T18:03:07Z",
        "id": "deviceid",
        "lastUpdated": "2019-10-02T18:03:07Z",
        "profile": {
            "diskEncryptionType": "ALL_INTERNAL_VOLUMES",
            "displayName": "Example Device name 1",
            "platform": "WINDOWS",
            "registered": true,
            "secureHardwarePresent": false,
            "serialNumber": "XXDDRFCFRGF3M8MD6D",
            "sid": "S-1-11-111"
        },
        "resourceAlternateID": "",
        "resourceDisplayName": {
            "sensitive": false,
            "value": "Example Device name 1"
        },
        "resourceID": "deviceid",
        "resourceType": "UDDevice",
        "status": "ACTIVE",
        "_links": {
            "activate": {
                "hints": {
                    "allow": [
                        "POST"
                    ]
                },
                "href": "https://localhost/api/v1/devices/deviceid/lifecycle/activate"
            },
            "self": {
                "hints": {
                    "allow": [
                        "GET",
                        "PATCH",
                        "PUT"
                    ]
                },
                "href": "https://localhost/api/v1/devices/deviceid"
            },
            "users": {
                "hints": {
                    "allow": [
                        "GET"
                    ]
                },
                "href": "https://localhost/api/v1/devices/deviceid/users"
            }
        },
        "users": [
            {
                "id": "userid",
                "status": "RECOVERY",
                "created": "2023-05-14T13:37:20Z",
                "activated": "0001-01-01T00:00:00Z",
                "statusChanged": "2023-05-15T01:50:30Z",
                "lastLogin": "2023-05-15T01:59:20Z",
                "lastUpdated": "2023-05-15T01:50:32Z",
                "passwordChanged": "2023-05-15T01:50:32Z",
                "type": {
                    "id": "typeid"
                },
                "profile": {
                    "login": "name.surname@example.com",
                    "email": "name.surname@example.com",
                    "firstName": "name",
                    "lastName": "surname"
                },
                "credentials": {
                    "password": {},
                    "provider": {
                        "type": "OKTA",
                        "name": "OKTA"
                    }
                },
                "_links": {
                    "self": {
                        "href": "https://localhost/api/v1/users/userid"
                    }
                }
            }
        ]
    },
    "device": {
        "id": "deviceid",
    },
    "labels": {
        "identity_source": "okta-1"
    }
}



Full synchronizations will be bounded on either side by "write marker" documents.

		{
    "@timestamp": "2022-11-04T09:57:19.786056-05:00",
    "event": {
        "action": "started",
        "start": "2022-11-04T09:57:19.786056-05:00"
    },
    "labels": {
        "identity_source": "okta-1"
    }
}



Logs reference

Device

This is the Device dataset.

Field	Description	Type
@timestamp	Event timestamp.	date
asset.category		keyword
asset.costCenter		keyword
asset.create_date		date
asset.id		keyword
asset.last_seen		date
asset.last_status_change_date		date
asset.last_updated		date
asset.name		keyword
asset.status		keyword
asset.type		keyword
asset.vendor		keyword
data_stream.dataset	Data stream dataset.	constant_keyword
data_stream.namespace	Data stream namespace.	constant_keyword
data_stream.type	Data stream type.	constant_keyword
device.serial_number	The unique serial number serves as a distinct identifier for each device, aiding in inventory management and device authentication.	keyword
entityanalytics_okta.device._embedded	embedded resources related to the device.	flattened
entityanalytics_okta.device._links	link relations for the device's current status.	flattened
entityanalytics_okta.device.activated	timestamp when transition to ACTIVE status completed.	date
entityanalytics_okta.device.created	timestamp when device was created.	date
entityanalytics_okta.device.id	unique key for device.	keyword
entityanalytics_okta.device.last_login	timestamp of last login.	date
entityanalytics_okta.device.last_updated	timestamp when device was last updated.	date
entityanalytics_okta.device.password_changed	timestamp when password last changed.	date
entityanalytics_okta.device.profile.*		keyword
entityanalytics_okta.device.profile.registered	Whether the device is registered.	boolean
entityanalytics_okta.device.profile.secure_hardware_present	Whether the device is using secure hardware.	boolean
entityanalytics_okta.device.status	current status of device.	keyword
entityanalytics_okta.device.status_changed	timestamp when status last changed.	date
entityanalytics_okta.device.transitioning_to_status	target status of an in-progress asynchronous status transition.	keyword
entityanalytics_okta.device.type	device type that determines the schema for the device's profile.	flattened
entityanalytics_okta.device.users	Users associated with the device.	flattened
event.dataset	Event dataset.	constant_keyword
event.module	Event module.	constant_keyword
input.type	Type of filebeat input.	keyword
labels.identity_source		keyword
log.offset	Log offset.	long
user.account.activated_date		date
user.account.change_date		date
user.account.create_date		date
user.account.password_change_date		date
user.account.status.deprovisioned		boolean
user.account.status.locked_out		boolean
user.account.status.password_expired		boolean
user.account.status.recovery		boolean
user.account.status.suspended		boolean
user.geo.city_name		keyword
user.geo.country_iso_code		keyword
user.geo.name		keyword
user.geo.postal_code		keyword
user.geo.region_name		keyword
user.geo.timezone		keyword
user.organization.name		keyword
user.profile.department		keyword
user.profile.first_name		keyword
user.profile.id		keyword
user.profile.job_title		keyword
user.profile.last_name		keyword
user.profile.manager		keyword
user.profile.mobile_phone		keyword
user.profile.other_identities		keyword
user.profile.primaryPhone		keyword
user.profile.secondEmail		keyword
user.profile.status		keyword
user.profile.type		keyword

User

This is the User dataset.

Field	Description	Type
@timestamp	Event timestamp.	date
asset.category		keyword
asset.costCenter		keyword
asset.create_date		date
asset.id		keyword
asset.last_seen		date
asset.last_status_change_date		date
asset.last_updated		date
asset.name		keyword
asset.status		keyword
asset.type		keyword
asset.vendor		keyword
data_stream.dataset	Data stream dataset.	constant_keyword
data_stream.namespace	Data stream namespace.	constant_keyword
data_stream.type	Data stream type.	constant_keyword
entityanalytics_okta.groups.id	The ID for the group.	keyword
entityanalytics_okta.groups.profile.*	Group profile details.	object
entityanalytics_okta.user._embedded	embedded resources related to the user.	flattened
entityanalytics_okta.user._links	link relations for the user's current status.	flattened
entityanalytics_okta.user.activated	timestamp when transition to ACTIVE status completed.	date
entityanalytics_okta.user.created	timestamp when user was created.	date
entityanalytics_okta.user.credentials.provider.name		keyword
entityanalytics_okta.user.credentials.provider.type		keyword
entityanalytics_okta.user.credentials.recovery_question.is_set		boolean
entityanalytics_okta.user.id	unique key for user.	keyword
entityanalytics_okta.user.last_login	timestamp of last login.	date
entityanalytics_okta.user.last_updated	timestamp when user was last updated.	date
entityanalytics_okta.user.password_changed	timestamp when password last changed.	date
entityanalytics_okta.user.profile.city	City or locality component of user's address (locality).	keyword
entityanalytics_okta.user.profile.cost_center	Name of a cost center assigned to user.	keyword
entityanalytics_okta.user.profile.country_code	Country name component of user's address (country).	keyword
entityanalytics_okta.user.profile.department	Name of user's department.	keyword
entityanalytics_okta.user.profile.display_name	Name of the user, suitable for display to end users.	keyword
entityanalytics_okta.user.profile.division	Name of user's division.	keyword
entityanalytics_okta.user.profile.email	Primary email address of user.	keyword
entityanalytics_okta.user.profile.employee_number	Organization or company assigned unique identifier for the user.	keyword
entityanalytics_okta.user.profile.first_name	Given name of the user (givenName).	keyword
entityanalytics_okta.user.profile.honorific.prefix	Honorific prefix(es) of the user, or title in most Western languages.	keyword
entityanalytics_okta.user.profile.honorific.suffix	Honorific suffix(es) of the user.	keyword
entityanalytics_okta.user.profile.last_name	Family name of the user (familyName).	keyword
entityanalytics_okta.user.profile.locale	User's default location for purposes of localizing items such as currency, date time format, numerical representations, and so on.	keyword
entityanalytics_okta.user.profile.login	Unique identifier for the user (username).	keyword
entityanalytics_okta.user.profile.manager.id	id of a user's manager.	keyword
entityanalytics_okta.user.profile.manager.name	displayName of the user's manager.	keyword
entityanalytics_okta.user.profile.middle_name	Middle name(s) of the user.	keyword
entityanalytics_okta.user.profile.mobile_phone	Mobile phone number of user.	keyword
entityanalytics_okta.user.profile.nick_name	Casual way to address the user in real life.	keyword
entityanalytics_okta.user.profile.organization	Name of user's organization.	keyword
entityanalytics_okta.user.profile.postal_address	Mailing address component of user's address.	keyword
entityanalytics_okta.user.profile.preferred_language	User's preferred written or spoken languages.	keyword
entityanalytics_okta.user.profile.primary_phone	Primary phone number of user such as home number.	keyword
entityanalytics_okta.user.profile.second_email	Secondary email address of user typically used for account recovery.	keyword
entityanalytics_okta.user.profile.state	State or region component of user's address (region).	keyword
entityanalytics_okta.user.profile.street_address	Full street address component of user's address.	keyword
entityanalytics_okta.user.profile.timezone	User's time zone.	keyword
entityanalytics_okta.user.profile.title	User's title, such as "Vice President".	keyword
entityanalytics_okta.user.profile.url	URL of user's online profile (for example: a web page).	keyword
entityanalytics_okta.user.profile.user_type	Used to describe the organization to user relationship such as "Employee" or "Contractor".	keyword
entityanalytics_okta.user.profile.zip_code	ZIP code or postal code component of user's address (postalCode).	keyword
entityanalytics_okta.user.status	current status of user.	keyword
entityanalytics_okta.user.status_changed	timestamp when status last changed.	date
entityanalytics_okta.user.transitioning_to_status	target status of an in-progress asynchronous status transition.	keyword
entityanalytics_okta.user.type	user type that determines the schema for the user's profile.	flattened
event.dataset	Event dataset.	constant_keyword
event.module	Event module.	constant_keyword
input.type	Type of filebeat input.	keyword
labels.identity_source		keyword
log.offset	Log offset.	long
user.account.activated_date		date
user.account.change_date		date
user.account.create_date		date
user.account.password_change_date		date
user.account.status.deprovisioned		boolean
user.account.status.locked_out		boolean
user.account.status.password_expired		boolean
user.account.status.recovery		boolean
user.account.status.suspended		boolean
user.geo.city_name		keyword
user.geo.country_iso_code		keyword
user.geo.name		keyword
user.geo.postal_code		keyword
user.geo.region_name		keyword
user.geo.timezone		keyword
user.organization.name		keyword
user.profile.department		keyword
user.profile.first_name		keyword
user.profile.id		keyword
user.profile.job_title		keyword
user.profile.last_name		keyword
user.profile.manager		keyword
user.profile.mobile_phone		keyword
user.profile.other_identities		keyword
user.profile.primaryPhone		keyword
user.profile.secondEmail		keyword
user.profile.status		keyword
user.profile.type		keyword

Changelog

Version	Details	Kibana version(s)
2.4.0	Enhancement (View pull request) Remove redundant installation instructions.	8.15.0 or higher 9.0.0 or higher
2.3.0	Enhancement (View pull request) Retain Okta Domain value in `host.name` where possible.	8.15.0 or higher 9.0.0 or higher
2.2.1	Bug fix (View pull request) Fix default request trace enabled behavior.	8.15.0 or higher 9.0.0 or higher
2.2.0	Enhancement (View pull request) Improve rate limit documentation for integration.	8.15.0 or higher 9.0.0 or higher
2.1.0	Enhancement (View pull request) Update Kibana constraint to support 9.0.0.	8.15.0 or higher 9.0.0 or higher
2.0.0	Enhancement (View pull request) Split user and device data into their own data streams.	8.15.0 or higher
1.8.1	Bug fix (View pull request) Updated SSL description to be uniform and to include links to documentation.	8.15.0 or higher
1.8.0	Enhancement (View pull request) Add "event.original" field when "preserve_original_event" is set.	8.15.0 or higher
1.7.0	Enhancement (View pull request) Add "preserve_original_event" tag to documents with `event.kind` manually set to "pipeline_error".	8.15.0 or higher
1.6.0	Enhancement (View pull request) Add "preserve_original_event" tag to documents with `event.kind` set to "pipeline_error".	8.15.0 or higher
1.5.1	Bug fix (View pull request) Don't leak collection implementation details.	8.15.0 or higher
1.5.0	Enhancement (View pull request) Add support for group membership mapping. Enhancement (View pull request) Add system testing support for group membership.	8.15.0 or higher
1.4.0	Enhancement (View pull request) Add support for request trace logging.	8.15.0 or higher
1.3.0	Enhancement (View pull request) Record whether a user's credentials include a recovery question.	8.13.0 or higher
1.2.0	Enhancement (View pull request) Removed import_mappings. Update the kibana constraint to ^8.13.0. Modified the field definitions to remove ECS fields made redundant by the ecs@mappings component template.	8.13.0 or higher
1.1.0	Enhancement (View pull request) Set sensitive values as secret.	8.12.0 or higher
1.0.1	Enhancement (View pull request) Changed owners	8.9.0 or higher
1.0.0	Enhancement (View pull request) Release package as GA.	8.9.0 or higher
0.8.0	Enhancement (View pull request) Allow dataset selection.	—
0.7.0	Enhancement (View pull request) ECS version updated to 8.11.0.	—
0.6.1	Bug fix (View pull request) Fix mapping of group fields	—
0.6.0	Enhancement (View pull request) ECS version updated to 8.10.0.	—
0.5.0	Enhancement (View pull request) The format_version in the package manifest changed from 2.11.0 to 3.0.0. Removed dotted YAML keys from package manifest. Added 'owner.type: elastic' to package manifest.	—
0.4.0	Enhancement (View pull request) Add tags.yml file so that integration's dashboards and saved searches are tagged with "Security Solution" and displayed in the Security Solution UI.	—
0.3.0	Enhancement (View pull request) Add user.geo., user.organization., and asset categorization mappings.	—
0.2.0	Enhancement (View pull request) Update package to ECS 8.9.0.	—
0.1.0	Enhancement (View pull request) Initial Release.	—
