Most sophisticated malware nowadays adds a "jitter" or randomness to the beacon interval, making the signal more difficult to detect. Some malware authors also use longer beacon intervals. The beaconing identification framework we propose accounts for some of these elusive modifications to traditional beaconing behavior.

Our approach

We’ve discussed a bit about the why and what — in this section we dig deeper into how we identify beaconing traffic. Before we begin, it is important to note that beaconing is merely a communication characteristic. It is neither good nor evil by definition. While it is true that malware heavily relies on beaconing nowadays, a lot of legitimate software also exhibits beaconing behaviour.

While we have made efforts to reduce false positives, this framework should be looked at as a means for beaconing identification to help reduce the search space for a threat hunt, not as a means for detection. That said, indicators produced by this framework, when combined with other IoCs, can potentially be used to detect on malicious activity.

The beacons we are interested in comprise traffic from a single running process on a particular host machine to one or more external IPs. Given that the malware can have both short (order of seconds) and long (order of hours or days) check-in intervals, we will restrict our attention to a time window that works reasonably for both and attempt to answer the question: “What is beaconing in my environment right now or recently?” We have also parameterized the inputs to the framework to allow users to configure important settings like time window, etc. More on this in upcoming sections.

When dealing with large data sets, such as network data for an enterprise, you need to think carefully about what you can measure, which allows you to scale effectively. Scaling has several facets, but for our purposes, we have the following requirements:

Work can be parallelised over different shards of data stored on different machines
The amount of data that needs to move around to compute what is needed must be kept manageable.

Multiple approaches have been suggested for detecting beaconing characteristics, but not all of them satisfy these constraints. For example, a popular choice for detecting beacon timing characteristics is to measure the interval between events. This proves to be too inefficient to use on large datasets because the events can't be processed across multiple shards.

Driven by the need to scale, we chose to detect beaconing by bucketing the data in the time window to be analyzed. We gather the event count and average bytes sent and received in each bucket. These statistics can be computed in MapReduce fashion and values from different shards can be combined at the coordinating node of an Elasticsearch query.

Furthermore, by controlling the ratio between the bucket and window lengths, the data we pass per running process has predictable memory consumption, which is important for system stability. The whole process is illustrated diagrammatically below:
