Ceph moduleedit

Warning

This functionality is in beta and is subject to change. The design and code is less mature than official GA features and is being provided as-is with no warranties. Beta features are not subject to the support SLA of official GA features.

The Ceph module collects metrics by submitting HTTP GET requests to the ceph-rest-api. The default metricsets are cluster_disk, cluster_health, monitor_health, pool_disk, osd_tree.

Compatibilityedit

The Ceph module is tested with Ceph Jewel (10.2.10).

Example configurationedit

The Ceph module supports the standard configuration options that are described in Specify which modules to run. Here is an example configuration:

metricbeat.modules:
- module: ceph
  metricsets: ["cluster_disk", "cluster_health", "monitor_health", "pool_disk", "osd_tree"]
  period: 10s
  hosts: ["localhost:5000"]
  enabled: true

This module supports TLS connections when using ssl config field, as described in Specify SSL settings. It also supports the options described in Standard HTTP config optionsedit.

Metricsetsedit

The following metricsets are available:
